Phaser 6300/6350/6360 Color Laser Printer Service Manual A-7
Reference
77 Image Density Error. Density firmware failure.
78 Engine Firmware Failure 78. CRUM data firmware failure.
79 Engine Firmware Failure 79. Generic firmware failure.
80 Hard Drive Failure. IDE Hard Disk failure.
81 Engine Communication Failure. Unable to properly communicate with the Engine
Control Board.
83 Engine NVRAM Failure. Engine Control Board NVRAM error.
86 Cyan Toner Cartridge Failure. Cyan cartridge CRUM data error.
87 Magenta Toner Cartridge Failure. Magenta cartridge CRUM data error.
88 Yellow Toner Cartridge Failure. Yellow cartridge CRUM data error.
89 Black Toner Cartridge Failure. Black cartridge CRUM data error.
90 Replace Cyan Toner Cartridge. The Cyan Toner Cartridge CRUM indicates that the
cartridge is not a Xerox product (CRUM ID error).
91 Replace Magenta Toner Cartridge. The Magenta Toner Cartridge CRUM indicates
that the cartridge is not a Xerox product (CRUM ID error).
92 Replace Yellow Toner Cartridge. The Yellow Toner Cartridge CRUM indicates that
the cartridge is not a Xerox product (CRUM ID error).
93 Replace Black Toner Cartridge. The Black Toner Cartridge CRUM indicates that
the cartridge is not a Xerox product (CRUM ID error).
94 Non-Phaser 6300 Fuser. The Fuser CRUM indicates that the installed Fuser is not
a 6300/6350 replacement part (Fuser CRUM ID error).
95 Non-Xerox Imaging Unit. The Imaging Unit CRUM indicates that the Imaging Unit
is not a genuine Xerox replacement part.
96 Replace Non-Xerox Cyan Toner Cartridge. User selected to not to use a third-
party Toner Cartridge when prompted.
97 Replace Non-Xerox Magenta Toner Cartridge. User selected to not to use a third-
party Toner Cartridge when prompted.
98 Replace Non-Xerox Yellow Toner Cartridge. User selected to not to use a third-
party Toner Cartridge when prompted.
99 Replace Non-Xerox Black Toner Cartridge. User selected to not to use a third-
party Toner Cartridge when prompted.
101 Replace Maintenance Kit. A Developer Assembly has reached its End of Life
count of approx. 300K. At 360K, the error becomes a hard stop.
102 Environment Sensor Failure. This indicates a Temperature/Humidity Sensor
signal failure.
103 Fuser Motor Failure. This indicates a Fuser Motor rotation signal error.
104 Developer Motor Failure. This indicates a Developer Motor rotation signal error.
105 Main Motor Failure. This indicates a Main Drive Motor rotation signal error.
106 Motor Failure. General motor error.
150 Close Front Door. The Interlock Switch indicates that Door A or B is open.
Printer Status Codes (Continued)
Code Description

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
