Xerox Phaser 6360 Service Manual

A-8 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Reference
151 Dusty Density Sensor. The CTD (ADC) Sensor does not reach reference voltage.
152 Jam at Fuser. The Fuser Exit Sensor indicates that paper remains in the Fuser.
153 Jam at Duplex. The Duplex Jam Sensor indicates that paper remains in the chute.
154 Jam at Registration Roller. The Registration Sensor indicates paper in the rollers.
155 Misfeed at Tray 1 (MPT). Paper from Tray 1 did not reach the Registration Sensor
on time.
156 Misfeed at Tray 2. Paper from Tray 2 did not reach the Registration Sensor on
time.
157 Misfeed at Tray 3. Paper from Tray 3 did not reach the Registration Sensor on
time.
158 Misfeed at Tray 4. Paper from Tray 4 did not reach the Registration Sensor on
time.
159 Misfeed at Tray 5. Paper from Tray 5 did not reach the Registration Sensor on
time.
160 Insert Tray 2. The Tray 2 Paper Size Switch indicates Tray 2 is missing.
161 Insert Tray 3. The Tray 3 Paper Size Switch indicates Tray 3 is missing.
162 Insert Tray 4. The Tray 4 Paper Size Switch indicates Tray 4 is missing.
163 Insert Tray 5. The Tray 5 Paper Size Switch indicates Tray 5 is missing.
164 Unsupported Configuration. Indicates more than one 550-Sheet Feeder is
installed.
165 Out of paper: Load Tray 1 (MPT) with [size] [type]. The print job requests paper
from Tray
1, but the Tray 1 (MPT) No Paper Sensor indicates an empty tray.
166 Out of paper: Load Tray 2 with [size] [type]. The print job requests paper from
Tray 2, but the Tray 2 No Paper Sensor indicates an empty tray.
167 Out of paper: Load Tray 3 with [size] [type]. The print job requests paper from
Tray 3, but the Tray 3 No Paper Sensor indicates an empty tray.
168 Out of paper: Load Tray 4 with [size] [type]. The print job requests paper from
Tray 4, but the Tray 4 No Paper Sensor indicates an empty tray.
169 Out of paper: Load Tray 5 with [size] [type]. The print job requests paper from
Tray 5, but the Tray 5 No Paper Sensor indicates an empty tray.
170 Manual Feed [size] [type]. The print job requests a manual feed of [size] [type].
171 Paper Not Available Load Tray 1 (MPT) with [size] [type]. The Paper Size Switch
indicates that the paper loaded in Tray 1 (MPT) does not match the size specified
by the print job.
172 Paper Not Available Load Tray 2 with [size] [type]. The Paper Size Switch
indicates that the paper loaded in Tray 2 does not match the size specified by the
print job.
173 Paper Not Available Load Tray 3 with [size] [type]. The Paper Size Switch
indicates that the paper loaded in Tray 3 does not match the size specified by the
print job.
Printer Status Codes (Continued)
Code Description

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
