Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Service Manual 10-3
Wiring Diagrams
52 3 H-143 Connects Engine Control Board and TNRFULL/FSR
Harness.
60 3 I-143 Connects the Engine Control Board and 24 V Harness.
61 3 H-143 Connects the Engine Control Board and LV Harness.
120 3 G-137 Connects the Engine Control and Image Processor Boards.
132 1 H-109 Connects the Tray 1 Feed Solenoid and FRONT/DUP
Harness.
133 1 D-108 Connects the Duplex Jam Sensor and FRONT/DUP
Harness.
134 1 F-106 Connects the Full Stack Sensor and FRONT/DUP Harness.
135 1 E-109 Connects Tray 1 No Paper Sensor and FRONT/DUP
Harness.
136 2 D-122 Connects the CTD (ADC) Sensor and FSR/ADC Harness.
137 3 B-137 Connects the Wire Assy Regi to the Registration Roller
Assy.
138 3 B-136 Connects the Wire Assembly BTR to the Transfer Roller.
139 3 E-133 Connects the HVPS and Wire Assembly BTR.
140 3 E-133 Connects the HVPS and Wire Assembly Regi.
141 3 E-135 Connects the HVPS and HVPS Harness.
142 2 E-122 Connects the Toner Full Sensor and TNR FULL/FSR
Harness.
144 2 H-121 Connects the EEPROM Board and EEPROM Harness.
151 2 H-120 Connects the Laser Unit and ROS Harness.
154 3 F-142 Not Connected
160 2 I-128 Connects the LVPS and AC Inlet.
161 2 I-126 Connects the LVPS and Interlock Switch.
162 2 I-128 Connects the LVPS and FSR/ADC Harness.
163 2 I-126 Connects the LVPS and 24 V Harness.
164 2 I-127 Connects the LVPS and LV PRG Harness.
165 2 I-127 Connects the LVPS and LV Harness.
166 2 I-126 Connects the LVPS and Rear Fan.
167 2 I-126 Connects the LVPS Fan to the LVPS.
171 4 G-154 Connects the Option Feeder and OPFPLG Harness.
181 3 E-138 Connects the Registration Sensor and REGI SNS Harness.
190 3 F-138 Connects the Tray 1 (MPT) Turn Clutch and FRONTCLH.
191 3 G-143 Connects the Engine Control Board and EEPROM Harness.
192 3 F138 Connects the Registration Clutch and FRONTCLH Harness.
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
