3-12 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Error Messages and Codes
2 Remove the Fuser and check for
broken or bent pins.
Replace the parts
concerned.
Go to Step 3.
3 Reinstall the Fuser.
Does error recur after the Fuser
Assembly has been replaced?
Go to Step 4. Complete
4 Test the Exit Sensor.
Run the Service Diagnostics Exit
Sensor Test.
Does the sensor function correctly?
Go to Step 7. Go to Step 5.
5 Check the Exit Sensor Signal.
Insert a sheet of paper into the Fuser.
Is the voltage across J361-A5 <=>
J361-A6 0 V?
Go to Step 7. Go to Step 6.
6 Check all pins on the FSR/ADC
Harness PL5.2.28 for continuity.
1. Disconnect P/J361 and P/J36.
2. Check continuity between
J361<=>J36.
Go to Step 7. Replace the FSR/
ADC Harness.
7 If possible print one sheet of paper.
Does the Fuser Motor Turn?
Inspect and
replace defective
gear(s).
Go to Step 8.
8 Test the Fuser Drive Assembly.
Run the Service Diagnostics Fuser
Motor test.
Does the Fuser Motor function
correctly?
Replace the
Engine Control
Board
(
page 8-106).
Go to Step 10.
9 Check for +24 V to the Fuser Motor.
Disconnect P/J521.
Is there +24 V across J521-10 <=>
ground?
Go to Step 11. Replace the
Engine Control
Board
(
page 8-106).
10 Replace the Fuser Drive Assembly.
Does the Fuser Motor function
correctly?
Complete Go to Step 11.
11 Check TNRFULL/FSR Harness
continuity.
1. Disconnect P/J52 and P/J521.
2. Check continuity between J52 <=>
J521.
Replace the
Engine Control
Board
(
page 8-106).
Replace the
TNRFULL/FSR
Harness.
Troubleshooting Procedures Table (Continued)
Step Action and Questions Yes No

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
