Xerox Phaser 6360 Service Manual

4-8 Phaser 6300/6350/6360 Service Manual
General Troubleshooting
Control Panel Shortcuts
The following are Control Panel button sequences that provide shortcuts to
specific commands when pressed while turning On the printer’s power.
N
o
t
e
The best method of exiting Service Diagnostics is to cycle printer power.
This insures all printer components are reset. Also, an occasional paper
jam is normal on the first print if clutch or solenoid tests were run.
Hidden Service Menu
The Hidden Service menu includes a list of functions providing direct access
to Service Diagnostics, the Developer Assembly counters, and the Enable
Metered Toner routine. Access the Hidden Service menu as follows:
1. Highlight Troubleshooting --> Service Tools.
2. With the cursor at the top of the Service Tools menu, press both the Up
Arrow and Down Arrow buttons.
Mode Buttons Pressed at Power On
Skip POST Diagnostics OK
Print Service Diagnostics Menu
Map
Help (?)
Reset PostScript NVRAM Back + OK
Password Bypass Up Arrow + Down Arrow
Enter Service Diagnostics Back + Help (?)
Control Panel Language Cancel + Help (?)

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
