Xerox Phaser 6360

Phaser 6300/6350/6360 Color Laser Printer Service Manual 7-7
Cleaning and Maintenance
13. Remove the screw (metal with flange, 6 mm) that secures the Left Side
Cover.
14. Release the hook on the front that holds the Left Side Cover and slide the
cover rearward to remove.
s6360-136
Hook
