8-80 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Service Parts Disassembly
7. Lift the Developer Frame Assembly to remove.
Replacement Note
Carefully match the colors of the 4 toner nozzles to the correct
positions. Check that each nozzle is locked to the Developer Frame
Assembly before replacing the covers. Also, reset the Developer Life
Counters after replacing the Developer Assemblies.
s6360-196
P/J484
