8-146 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Service Parts Disassembly
6. Disconnect the Low Paper Sensor connector (P/J823).
7. Release the three hooks and remove the Low Paper Sensor.
s6360-239
P/J823
