Xerox Phaser 6360

Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-5
Parts List
Parts List 1.1 Covers - Service Parts List
No. Part Number Name/Description
1.
116-1964-00 Cover Assy Top (with 2,3), (6300/6350)
2. 802E95621 Cover, Top, (6360)
3. 116-2044-00 Cover Top Stopper
4. 802E76574 Cover Top Main
5. 333-4419-00
333-4424-00
101E28720
Control Panel, (6300)
Control Panel, (6350)
Control Panel, (6360)
6. 116-1966-00
802K91992
Cover Assy Front (with 7), (6300/6350)
Cover Assy Front (with 7), (6360)
7. Lever Out
8. 116-1967-00
802K98890
Cover Assy Top (Door C) (with 9~16), (6300/6350)
Cover Assy Top (Door C) (with 9~16), (6360)
9. Spring L/R
10. Plunger
11. Cover Top Phd
12. Latch Top L
13. Shaft Latch
14. Latch Top Ir R
15. Latch Top R
16. Spring Stopper Bottom
17. Cover Assy Rear (with 18,19)
18. 116-1968-00
802E95631
Cover Rear, (6300/6350)
Cover Rear, (6360)
19. 127E83840 Fan Rear
20. 802K74543 Cover Side Right
21. Stud Top
22. 802E75932 Cover Front Right
23. 050K58270 Tray 1 (MPT) Base
24. Part of Tray
Holder Kit
Holder Tray Right
25. 802K74593 Tray 1 (MPT) (with 26, 27)
26. Tray 1 (MPT) Slide
27. Cover Tray 1 (MPT)
28. 116-1974-00
802K91050
Cover Front Left, (6300/6350)
Cover Front Left, (6360)
29. Part of Tray
Holder Kit
Holder, Tray Left
30. 802K74534 Cover Side Left
31. 127E84830 LVPS Fan (6360)
