Xerox Phaser 6360

Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-19
Parts List
Parts List 5.1 Chute Assembly In and Out - Service Parts List
ID No. Part Number Name/Description
1. 115R00035
115R00036
115R00055
115R00056
Fuser Assy 110V (with 2,3), (6300/6350)
Fuser Assy 220V (with 2,3), (6300/6350)
Fuser Assy 110V (with 2,3), (6360)
Fuser Assy 220V (with 2,3), (6360)
2. Part of Actuator
Kit
Actuator Exit
3. 809E34550 Spring Actuator
4. 108R00646 Transfer Roller (Unit) (BTR)
5. 003E63190 Stopper Strap
6. Part of Spring Kit Spring Link
7. 012E12034 Link
8. Shaft Pivot R
9. Shaft Pivot L
