Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-25
Parts List
Parts List 5.4 Chute Assembly Duplex - Service Parts List
ID No. Part Number Name/Description
1. 130E87090 Sensor Photo (Full Stack Sensor)
2. Part of Actuator
Kit
Actuator Full Stack
3. Part of Spring Kit Spring Pinch Exit
4. Roll Pinch Exit
5. 116-2002-00
127K49770
Duplex Motor Assy, (6300/6350)
Duplex Motor Assy, (6360)
6. Part of Gear Kit Gear 52
7. Gear 40/66h
8. Bearing
9. Gear Exit/dup
10. Gear 41
11. Chute Dup Out
12. Holder Sensor Dup
13. 116-1421-00 Actuator Duplex Jam (Part of Actuator Kit)
14. 116-1423-00 Actuator Spring Duplex Jam (Part of Spring Kit)
15. Roll Dup
16. Roll Exit
17. - -
18. Eliminator Exit
19. Bearing Earth
20. Holder Roll
21. Roll Corrugate
22. Spring Corrugate
23. Cover Gear Dupout
24. Upper Exit Cover - Not included with PL5.3.1
25. Jam Sensor Assy (1, 12~14)
26. Bearing, Exit
