Xerox Phaser 6360

Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-29
Parts List
Parts List 7.1 Development (1/2) - Service Parts List
ID No. Part Number Name/Description
1. 116-2007-00
801K28980
Developer Frame Assy (with 2~16), (6300/6350)
Developer Frame Assy (with 2~16), (6360)
2. Spring L
3. Stopper Deve L
4. 130K60470 CRUM Connector
5. Spring Plunger
6. Plunger Frame
7. 962K38550 Harness Assy PHD2 (J484-J710)
8. Frame Deve
9. Cover Assy Frame
10. Gear Assy Duct
11. Spring R
12.
Stopper Deve R
13. 809E58680 Spring Tracking (Qty. 1)
14. Shutter Duct
15. Spring Shutter Duct
16. Nozzle Assy Duct
17. 116-2008-00
848K03840
Developer Assy (Y), (6300/6350)
Developer Assy (Y), (6360)
18. 116-2009-00
848K03850
Developer Assy (M), (6300/6350)
Developer Assy (M), (6360)
19. 116-2010-00
848K03860
Developer Assy (C), (6300/6350)
Developer Assy (C), (6360)
20. 116-2011-00
848K03870
Developer Assy (K), (6300/6350)
Developer Assy (K), (6360)
21. 032E22532 Guide Frame Deve Left
22. 032E22522 Guide Frame Deve Right
