Xerox Phaser 6360

Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-31
Parts List
Parts List 7.2 Development (2/2) - Service Parts List
ID No. Part Number Name/Description
1. 116-2014-00
604K38410
Holder, Toner Cartridge Assy, Yellow (with 5~7) (6300/6350)
Holder, Toner Cartridge Assy, Yellow (with 5~7) (6360)
2. 116-2015-00
604K38420
Holder, Toner Cartridge Assy, Magenta (with 5~7)(6300/6350)
Holder, Toner Cartridge Assy, Magenta (with 5~7) (6360)
3. 116-2016-00
604K38430
Holder, Toner Cartridge Assy, Cyan (with 5~7) (6300/6350)
Holder, Toner Cartridge Assy, Cyan (with 5~7) (6360)
4. 116-2017-00
604K38440
Holder, Toner Cartridge Assy, Black (with 5~7) (6300/6350)
Holder, Toner Cartridge Assy, Black (with 5~7) (6360)
5. 130E88130 Sensor No Toner
6. 849E04740 Switch Bracket, Toner CTG-IN
7. 020E36250 Actuator Toner CTG-IN
8. See
(
page 9-60)
Toner Cartridge (Y)
9. See
(
page 9-60)
Toner Cartridge (M)
10. See
(
page 9-60)
Toner Cartridge (C)
11. See
(
page 9-60)
Toner Cartridge (K)
12. 116-2018-00
101K53960
Box Assy CRUM Reader (With 13~16) (6300/6350)
Box Assy CRUM Reader (With 13~16) (6360)
13. Cover Holder CRUM
14. Coil Assy CRUM Reader
15. Hsg Base CRUM
16. Harness Assy RFID2 (J341-J3411)
17. 962K28000 Harness Assy RFID (J34-P3411)
18. Part of Wiring
Harness Kit
Harness Assy TNR
(J51-J342,P511,P512,P513,P514,J701,J702,J703,J704) )
19. Clamp Mini-sdl
20. Bracket Holder Dsp
21. Saddle Bush
22. Dispenser Toner Hi Assy (With 1-7,12-21)
23. 054E30181 LV Fan Duct (6360)
