Xerox Phaser 6360

Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-35
Parts List
Parts List 9.1 Electrical - Service Parts List
ID No. Part Number Name/Description
1. - -
2. Plate Assy Rear
3. 650-4365-00
960K41681
Image Processor Board (with 2, 28~31) (6300/6350)
Image Processor Board (with 2, 28~31) (6360)
4. Box Assy LVPS
5. -
6a.
6b.
116-2037-00
604K38460
116-2038-00
604K38470
Low Voltage Power Supply (LVPS), 110V (with 4, 7)
Low Voltage Power Supply (LVPS), 110V (with 4, 7) (6360)
Low Voltage Power Supply (LVPS), 220V (with 4, 7)
Low Voltage Power Supply (LVPS), 230V (with 4, 7) (6360)
7. Harness Assy AC Inlet
8. - -
9. Clamp
10. 675K17830
675K05330
Power Cord 110V (6300/ 6350/6360)
Power Cord 220V (6360)
11. 962K28211 Interlock Switch Assy
12. 960K05780 EEPROM Circuit Board
13. 019E49010 Clamp Guide Harness
14. Guide Harness R
15. Guide Harness F
16. 116-2036-00
604K38453
Engine Control (MCU) Circuit Board (with 17) (6300/6350)
Engine Control (MCU) Circuit Board (with 17) (6360)
17. Bracket Assy MCU
18. Cover Elec
19. Bracket Temp
20. 130E87990 Temperature/Humidity Sensor
21. 116-2041-00
105K22062
High Voltage Power Supply (HVPS) Board (6300/6350)
High Voltage Power Supply (HVPS) Board (6360)
22. 163-1521-00
069E00510
Configuration Card, N configuration (6300)
Configuration Card, N configuration (6360)
23. 163-1525-00
069E00520
Configuration Card, DN configuration (6300)
Configuration Card, DN configuration (6360)
24. 163-1522-00 Configuration Card, DP configuration (6350)
25. 807E23330 Internal Hard Drive
26. 237E23640 256 MB, DIMM DDR Lead Free
27. 237E23650 512 MB, DIMM DDR Lead Free
28. 116-1459-00
237E24050
IP Board NVRAM (6300/6350)
IP Board NVRAM (6360)
29. PWB Bracket Left
30. PWB Bracket Right
31. Block PWB
