Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-39
Parts List
Parts List 11.1 550-Sheet Feeder (1/2) - Service Parts List
ID No. Part Number Name/Description
1. 059K59790 550-Sheet Feeder (with 2-17,PL11.2~11.4)
2. Screw Joint
3. Cover Front
4. Frame Assy Top Front
5. Frame Assy Top Rear
6. Part of Wiring
Harness Kit
Harness Assy OPFREC (J83-J171)
7. Plate Connector
8. PWB Assy (with 9,10)
9. Plate PWBA
10. 960K03290 PWBA OPTFDR
11. Cover Right
12. Plate Bottom Rear
13. Harness Assy OPFPLG2 (J84-P172)
14. Plate Bottom Front
15. 054K28372 Feeder Chute
16. Cover Left
17. 802E78002 Cover, Paper Tray Rear
