Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-43
Parts List
Parts List 11.3 Tray 3 Paper Pick Assembly - Service Parts List
ID No. Part Number Name/Description
1. Paper Pick (Pickup Assy) Assembly (with 2~14,16~23,
26)
2. Roll Assy Turn
3. Bearing (F6xL8)/Metal
4. Clutch Assy
5. Gear Idle 21/29
6. Stopper Clutch
7. 130E87090 Sensor Photo (No Paper, Low Paper Sensor)
8. Gear Feed2
9. Gear Idler Feed
10. Part of Spring Kit Spring Feed H
11. Solenoid Feed
12. Gear Feed H2
13. Gear Feed H1
14. Gear 24
15. Drive Assy
16. Part of Actuator
Kit
Actuator Low Paper
17. Chute Upper
18. Bearing (F6xL8)/Black
19. Shaft Assy Feed
20. Part of Paper
Feed Roller Kit
Roll Assy Nudger x 2
21. Shaft Assy Nudger
22. Part of Actuator
Kit
Actuator No Paper
23. Frame Assy Pickup
24. Harness Assy OPFDR (J85-J822,P824,P825)
25. Harness Assy LOWP (J81-J823)
26. Guide Paper

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
