Xerox Phaser 6360

Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-51
Parts List
Parts List 12.3 Harness - Service Parts List
ID No. Part Number Name/Description
1. Part of Wiring
Harness Kit
Harness Assy OPFREC2 (J83-J172)
2. Spacer
3. 960K03290 Circuit Board HCF (OPTFDR 2 PWBA)
4. Harness Assy OPF23 (J83-J84)
5. Harness Assy SIZE2 (J80-J821)
6. Harness Assy LOWP2 (J81-J823)
7. Harness Assy OPFDR2 (J85-J822, P824, P825)
8. Clamp Saddle
9. 005K07320 Drive Assy HCF
10. Gear 24
11. Clamp
