Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-53
Parts List
Parts List 12.4 Paper Pick Assembly HCF T1 - Service Parts List
ID No. Part Number Name/Description
1. 604K28602 Paper Pick Assembly HCF T1 (with 2~18, 20~22)
2. Roll Assy Turn
3. Bearing (F6xL8)/Metal
4. Clutch Assy
5. Gear Idle 21/29
6. Stopper Clutch
7. 130E87090 Sensor Photo (No Paper, Low Paper Sensor)
8. Gear Feed2
9. Gear Idler Feed
10. Part of Spring Kit Spring Feed H
11. Solenoid Feed
12. Gear Feed H2
13. Gear Feed H1
14. Gear 24
15. Part of Actuator
Kit
Actuator Low Paper
16. Chute Upper
17. Bearing (F6xL8)/Black
18. Shaft Assy Feed
19. Part of Paper
Feed Roller Kit
Roll Assy Nudger x 2
20. Shaft Assy Nudger
21. Part of Actuator
Kit
Actuator No Paper
22. Frame Assy Pickup
