Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-55
Parts List
Parts List 12.5 Paper Pick Assembly HCF T2 - Service Parts List
ID No. Part Number Name/Description
1. 604K28612 Paper Pick (Pickup Assy) Assembly HCF T2 (with 2~17,
19~21)
2. Roll Assy Turn
3. Bearing (F6xL8)/Metal
4. Clutch Assy
5. Gear Idle 21/29
6. Stopper Clutch
7. 130E87090 Sensor Photo (No Paper, Low Paper Sensor)
8. Gear Feed2
9. Gear Idler Feed
10. Spring Feed H
11. Solenoid Feed
12. Gear Feed H2
13. Gear Feed H1
14. Part of Actuator
Kit
Actuator Low Paper
15. Chute Upper
16. Bearing (F6xL8)/Black
17. Shaft Assy Feed
18. Part of Paper
Feed Roller Kit
Roll Assy Nudger x 2
19. Shaft Assy Nudger
20. Part of Actuator
Kit
Actuator No Paper
21. Frame Assy Pickup 4th
