Xerox Phaser 6360

10-14 Phaser 6300/6350/6360 Service Manual
Wiring Diagrams
Denotes a Clutch or Solenoid.
Denotes a Motor.
Denotes a photo sensor.
I/L +24VDC Denotes DC voltage when the interlock switch in
Engine Control Board turns on.
+5VDC
+3.3VDC
Denotes DC voltage.
SG Denotes signal ground.
Symbol Description
M
