Phaser 6300/6350/6360 Color Laser Printer Service Manual 2-29
Theory of Operation
Fuser Drive Assembly
Supplies the drive to the Fuser as shown in the following figure.
Fuser Drive Assembly
Heat Roll
s6360-343
Fuser
Gear Exit
Fuser Exit Roller
