Xerox Phaser 6360 Service Manual

2-34 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Theory of Operation
■ Duplex Motor
Drives the Exit and Duplex rollers as shown in the following figure. A
different version of this motor is used in the 6360 model.
■ Duplex Roller
Driven by the Duplex Motor, the Duplex Roller feeds the print media
returned from the Exit Roller to the Turn and Retard Rollers.
■ Feed Roller
When the Tray 1 (MPT) Feed Solenoid energizes, the Gear MPT and Idler
gear are engaged. The Feed Roller rotates feeding paper from Tray 1.
After rotating one turn, the Gear MPT and the Idler gear disengage, and
the Feed Roller stops, allowing only one sheet of paper to be fed through
at a time.
■ Envelope Rollers
These rollers assist in transporting envelopes or other custom media
sizes through Tray 1 (MPT).
■ Tray 1 (MPT) No Paper Sensor
Detects whether print media is present.
■ Tray 1 Feed Solenoid
Controls the operation (rotation/stop) of the Tray 1 (MPT) Feed Roller.
■ Exit Roller
Driven by the Duplex Motor, the Exit Roller moves the fused print media
partially into the output tray where it then reverses in duplex mode and
feeds the print media (fused on one side) in the direction of the
Registration Chute.
Duplex Motor
Chute Assembly Out
Gear 40/66H
Gear 52
Gear 40/66H
Gear 41
Gear Exit/Dup Gear 41
Exit Roller Gear Exit/Dup
Duplex Roller
s6360-344

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
