Xerox Phaser 7400 Service Manual

3-8 Phaser 7400 Color Printer Service Manual
Jam Errors (Continued)
FN8 Jam at Finisher Door G Open Door G to Clear 3-42
FN9 Jam at Finisher Saddle Stapler Open Door G to Clear 3-43
FN10 Jam at Finisher Upper Output Tray Remove paper from Finisher Output 3-44
IN1~IN4,
IN6, IN7
Jam Inside Finisher Open Door F and Door I to Clear 3-45
IN5, IN8 Jam at Finisher Entrance Separate Finisher Base from Printer 3-46
FT Finisher Output Tray Jammed Remove Obstruction to Clear 3-47
Door and Cover Errors
_ Close Top Cover 3-49
_ Close Right Door A 3-50
_ Close Right Door B 3-51
_ Open and Close Door B 3-51
_ Close Right Door C for Tray [3][4][5][6] 3-53
_ Close Left Door D 3-54
_ Close Duplex Unit 3-54
_ Close Left Door E 3-55
_ Close Finisher Door F 3-56
_ Close Finisher Door H 3-57
_ Close Finisher Door J 3-58
_ Reposition the Finisher (Finisher away from base) 3-184
_ Reposition the Finisher (Finisher away from printer) 3-185
Consumable/Routine Maintenance Item Errors
_ Replace [C][M][Y][K] Toner Cartridge 3-59
_ Replace [C][M][Y][K] Imaging Unit 3-60
_ Replace Transfer Unit 3-61
_ Replace Waste Cartridge 3-62
_ Replace Fuser 3-63
_ Install or Reseat [C][M][Y][K] Toner Cartridge 3-64
_ Install or Reseat [C][M][Y][K] Imaging Unit 3-65
_ Install or Reseat Transfer Unit 3-66
_ Install or Reseat Waste Cartridge+ 3-67
Error Message Summary (Continued)
Error Control Panel Message Page

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
