Xerox Phaser 7400 Service Manual

3-46 Phaser 7400 Color Printer Service Manual
Jam at Finisher Entrance
Media remains in the Inverter Entrance Sensor. This error represents a jam in the
Printer/Finisher interface.
Applicable Status Codes:
Code IN5: Media did not reach the Inverter Entrance Sensor following an Eject
command from the printer.
Code IN8: Media remains in the Inverter Entrance Sensor.
Initial Actions:
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Inverter Entrance Sensor ■ Options Map 3, Inverter Controller Board
■ Options Map 9, Inverter Sensor Locator
■ Options Inverter Sensors Diagram
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1
Check the following for evidence of fault,
damage, obstruction, or debris:
■ Sensor Actuator
■ Paper Guides
■ Transport Rollers
Are there any defects or misalignment?
Replace any
damaged parts.
Go to Step 2.
2
Test the Inverter Entrance Sensor.
Run the Service Diagnostics Inverter Input
Sensor test.
Does the sensor function correctly?
Replace the Engine
Control Board
(
page 8-112).
Go to Step 3.
3
Test the sensor signal.
Does the voltage change on SNSCNO-5
connector of the Inverter Control Board
when the sensor is actuated?
Replace the
Inverter Control
Board.
Either the sensor
or the wiring is
defective. Check
the resistance of
the wires and if no
problem is found
replace the sensor.

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
