Xerox Phaser 7400 Service Manual

3-102 Phaser 7400 Color Printer Service Manual
Imaging Unit Fan Failure
Applicable Status Code:
Code U11: Imaging Unit Fan Failure
Initial Actions:
■ Cycle the printer's power.
■ If the problem persists follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Imaging Unit Fan, PL6.1.23
■ IDFAN Harness, PL5.1.31
■ GTG0 Harness, PL5.1.32
■ Print Engine Map 7 (page 10-10)
■ Print Engine Map 8 (page 10-11)
■ Print Engine Imaging Unit Sensor Board (page 10-41)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1
Test the Imaging Unit Fan.
Run the Service Diagnostics Imaging Unit
Fan test.
Does the Fan operate correctly.
Replace the Engine
Control Board
(
page 8-112).
Go to Step 2.
2
Check the Fan connection.
Is P/J100 securely connected?
Replace the Fan
(
page 8-133). If the
error persists, go to
Step 3.
Connect the Fan.
3
Check for +24 V at the Fan.
Disconnect P/J100.
Is there +24 V between J100-1 <=>
ground?
Go to Step 4. Go to Step 5.
4
Check continuity of the IDFAN Harness.
Is the wiring harness conductive?
Go to Step 5. Replace the
harness.
5
Check for +24 V at the Imaging Unit
Sensor Board.
Disconnect CTG0.
Is there +24 V at CTG0-9?
Replace the
Imaging Unit
Sensor Board
(
page 8-142).
Go to Step 6.
6
Check continuity of the CTG0 Harness.
Is the wiring harness conductive?
Replace the Engine
Control Board
(
page 8-112)
Replace the
harness.

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
