Xerox Phaser 7400 Service Manual

General Information 1-3
Printer Configurations
The Phaser 7400 Color Printer is available in five configurations. The main
differences are standard memory, optional high-capacity feeders, duplexing (2-sided
printing) capabilities, networking, and internal Hard Drive. The following table lists
the available configurations.
Features
Printer Configuration
7400N 7400DN 7400DT 7400DX 7400DXF
Max Print Speed (ppm)
color / monochrome
36/40 36/40 36/40 36/40 36/40
Hard Drive for Secure,
Proof, Personal, and
Saved Print Jobs
Optional Optional Ye s Ye s Ye s
Standard Memory* 256 MB 256 MB 512 MB 512 MB 512 MB
USB Port Ye s Ye s Ye s Ye s Ye s
10/100 Ethernet Port Ye s Ye s Ye s Ye s Ye s
RAM Collation Ye s Ye s Ye s Ye s Ye s
Duplex Unit Optional Ye s Ye s Ye s Ye s
PostScript / PCL Fonts Ye s Ye s Ye s Ye s Ye s
Banner Sizes Ye s Ye s Ye s Ye s Ye s
Photo Modes Ye s Ye s Ye s Ye s Ye s
Resolutions (dpi):
Standard
Enhanced
600x600x1
1200x600x1
600x600x5
600x600x1
1200x600x1
600x600x5
600x600x1
1200x600x1
600x600x5
600x600x1
1200x600x1
600x600x5
600x600x1
1200x600x1
600x600x5
Tray 1 (MPT)** Ye s Ye s Ye s Ye s Ye s
Optional Trays ** Optional Optional 1 x 550 3 x 550 4 x 550
550-Sheet Feeder** Optional Optional Ye s Optional Ye s
1650-Sheet Feeder** Optional Optional Optional Ye s Ye s
1000-Sheet Finisher*** Optional Optional Optional Optional Ye s
* All configurations have two memory slots supporting 256 MB and 512 MB cards, up
to a maximum of 1 GB.
** Trays 1 and 2 are standard on all configurations. All configurations support
additional paper trays in the following combinations:
One 550-Sheet Feeder (Tray 3)
One 1650-Sheet Feeder (Trays 3, 4, and 5 or 4,5, and 6)
One 550-Sheet Feeder (Tray 3) and one 1650-Sheet Feeder (Trays 4, 5, and 6)
*** Requires a Hard Drive and a total of 4 optional trays for fitment.

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
