Xerox Phaser 7400 Service Manual

Error Messages and Codes 3-17
Unless otherwise specified, the following voltage tolerances are used:
Jam Error Procedures
For jam errors, perform these basic steps before you begin the troubleshooting
procedure to rule out factors not related to mechanical function.
1. Ask the customer about the paper types being used. If not on the recommended
list, determine if this is contributing to the problem. Recycled, multi-purpose or
copier paper tends to contaminate the paper path. Constant use of special papers
such as labels or business cards can also contribute to jamming.
2. Ensure the correct tray loading and setup procedures are followed (securing the
guides, selecting the correct paper type, fanning the paper, etc.).
3. Make every attempt to establish a jam rate prior to starting any work. If possible
print a Status page or Usage Profile report and note the page count between jams.
4. Determine if jamming is occurring in one tray but not another. This helps to
identify any dirty or defective parts.
5. Clear the paper path of any jams or paper debris.
6. Clean the Feed and Pick Rollers using a slightly damp (water only) lint free cloth.
7. Cycle printer power and retest.
If after following these steps, the printer continues to jam, go to the troubleshooting
procedure indicated by the error.
Jam at Door A Open Door A to Clear
Media reached Feed-Out Sensor #1, but did not arrive at the Registration Sensor #1 or
Transfer Unit Entrance Sensor on time. This error represents a misfeed jam for media
fed from Tray 1 (MPT).
Stated Measured
+3.3 VDC +3.135 to +3.465 VDC
+5.0 VDC +4.75 to +5.25 VDC
+24.0 VDC +21.6 to +26.4 VDC
0.0 VDC Less than +0.5 VDC

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
