Xerox Phaser 7400 Service Manual

Error Messages and Codes 3-89
Configuration Errors
Invalid or Missing Configuration Card
The printer’s Configuration Card is missing or defective.
Duplicate IP Address Detected
Another device on the network is using the IP address assigned to this printer.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Configuration Card, PL9.1.31
■ Image Processor Board, PL9.1.3
■ Print Engine Map 4 (page 10-7)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1
Check the Configuration Card installation.
Remove and reinsert the Configuration
Card.
Does the error still occur?
Replace the
Configuration Card.
If the problem
persists, replace the
I/P Board
(
page 8-113).
Problem solved.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Image Processor Board, PL9.1.3 ■ Print Engine Map 4 (page 10-7)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1
Check the TCP/IP Address stored in the
printer’s NVRAM.
Is the address correct for the printer?
Advise the
customer of the
address conflict.
Enter the correct
IP address.

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
