Xerox Phaser 7400

8-42 Phaser 7400 Color Printer Service Manual
Registration Clutch #2
1. Remove the Tray 2 Feeder (page 8-38).
2. Remove the E-clip that secures the clutch to the Registration Roller.
3. While holding the anti-rattle spring, remove the clutch from the roller shaft.
Registration Clutch #2
s7400-466
