Xerox Phaser 7400 Service Manual

Parts List 9-61
Sensor Kit
The Sensor Kit provides replacement sensor actuators.
Actuator Kit
The Actuator Kit provides replacement sensor actuators.
Sensor Kit Contents - 604K35590
Name/Description Quantity
Photo-Interrupter 6
Sensor-Regist-Sub-Assy 1
Sensor-Regist- Assy. 1
Photointerrupter(REWORK) (OHP Sensor) 1
Actuator Kit Contents - 604K35580
Name/Description Quantity
Spring-Torsion (IN2) 1
Lever-Sensor (IN2) 1
Lever-Sensor( WR) 1
Spring-Torsion (WR) 1
Lever-Exit_Sensor 1
Spring-SNS (F/R) 1
Lever-Stacker-Full-F 1
Lever-Stacker-Full-Sub 1
Lever-Paper-END 1
Spring-Paper-End (joboff) 1
Lever-Stacker-Full-FU 1
Lever-Hopping 1
Lever-Paper End (MPT) 1
Lever-Paper (MPT) 1
Spring-Paper (MPT) 1
Link-Inter-Lock 1
Spring-Inter-Lock 1
Lever-Sns-Dup2 1
Spring-SNS-Dup2 1

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
