Xerox Phaser 7400 Service Manual

General Information 1-17
Image Specifications
Environmental Specifications
Characteristic Specification
Maximum Print Area
Guaranteed Print Area
Minimum margins = 5 mm (0.2 in.) on all sides
Maximum paper size = 328 mm x 1200 mm (12.9 in.x 47.25 in.)
Minimum paper size = 105 mm x 148 mm (4.13 in. x 5.83 in.)
The printer prints images meeting the Print Quality Specification
except the margin area, which is 5.0 mm inside each edge of
the paper.
Skew < 1.0 mm across 220 mm image, < 1.5 mm from option trays
Registration
Leading Edge
Side Edge
Duplex (front to back)
± 1.0 mm
± 1.0 mm
±1.5 mm (A size), 2.2 mm (B size)
Parallelism ± 0.5 mm across 220 mm image
Linearity
Vertical
Horizontal
Slant
± 0.5 mm across 234 mm image
± 0.5 mm across 190 mm image
± 1.2 mm across 269 mm image
Characteristic Specification
Temperature
Operating
Storage
Transport
10 to 32
o
C (50 to 89.6
o
F)
0 to 43
o
C (32 to 109.4
o
F)
-10 to 43
o
C (-14 to 109.4
o
F)
Humidity (RH)
Operating
Storage
Transport
Relative Humidity (50 - 70% to assure the best print-quality)
20 - 80%
10 - 90%
10 - 90%
Altitude
Operating
Non-operating
0 to 2500 meters (8,000 ft.) at 25
o
C
0 to 6000 meters (20,000 ft.)
Acoustic Noise (db)
Standby
Power Saver
Printing
45.0db or less
43.0db or less
55.0db or less

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
