Xerox Phaser 7400 Service Manual

A-4 Phaser 7400 Color Printer Service Manual
Printer Status Codes
Printer status codes that appear in the Service Usage Profile at line 237, on the printer
Status page, and output by the Fault History utility are defined in the following table.
Refer to the
"Messages, Codes, and Procedures" on page 3-5 for additional
information.
Printer Status Codes
Code Description
A1 Jam at A1. Misfeed while feeding paper from Tray 1 (MPT).
A2 Jam at A2. Jam at the Duplex Unit entrance.
A3 Jam at A3. Jam while feeding paper from Tray 1 (MPT).
B1 Jam at B1. Jam while feeding paper from Tray 2.
C3 Jam at C3. Jam while feeding paper from Tray 3.
C4 Jam at C4. Jam while feeding paper from Tray 4.
C5 Jam at C5. Jam while feeding paper from Tray 5.
C6 Jam at C6. Jam while feeding paper from Tray 6.
D1 Jam at D1. Paper reversal jam in Duplex Unit.
D2 Jam at D2. Misfeed inside the Duplex Unit.
E1 Jam at E1. Finisher Stacker jam.
TC1 Jam at TC1. Jam at the Transfer Unit belt.
TC2 Jam at TC2. Jam in the Fuser.
TC3 Jam at TC3. Jam at the Duplex Unit entrance.
E12 Top Output Tray Stack Full Sensor detects a full stack in the tray.
E13 Side Output Tray Stack Full Sensor detects a full stack in the tray.
E14 Finisher Lower Tray Stack Full Sensor detects a full stack in the tray.
E15 Finisher Upper Tray (Stacker) Stack Full Sensor detects a full stack in the tray.
F1 Jam at FN1. Jam at the Finisher Punch.
F2 Jam at Finisher FN2. Jam at the Finisher Inverter entrance.
F3 Jam at Finisher FN3. Additional sheet detected in the input path.
F4 Jam at FN4. Jam in the Finisher upper paper path.
F5 Jam at FN5. Jam at the Finsiher Saddle Stitch.
F6 Jam at FN6. Jam at the Finisher offset.
F7 Jam at FN7. Jam in the Finisher Compiler Tray.
F8 Jam at FN8. Paper arrived late or not at all to the saddle transport path.

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
