Xerox Phaser 7400 Service Manual

9-60 Phaser 7400 Color Printer Service Manual
Service Kits
Service kits are developed to provide an easy means to obtain spare parts normally
asscociated with larger assemblies. A number of Service Kits have been developed for
the Phaser 7400. The following tables list each kit’s contents.
Feed Roller Kit
The Feed Roller Kit provides replacement rollers for the Feeder Assemblies.
Toner Cartridge Consumables
Description (capacity) Part Number
Yellow Toner Cartridge, Standard-Capacity (7.5K)
Yellow Toner Cartridge, High-Capacity (15K)
Yellow Toner Cartridge, Metered (15K)
106R01152
106R01079
106R01155
Magenta Toner Cartridge, Standard Capacity (7.5K)
Magenta Toner Cartridge, High-Capacity (15K)
Magenta Toner Cartridge, Metered (15K)
106R01151
106R01078
106R01154
Cyan Toner Cartridge, Standard-Capacity (7.5K)
Cyan Toner Cartridge, High-Capacity (15K)
Cyan Toner Cartridge, Metered (15K)
106R01150
106R01077
106R01153
Black Toner Cartridge, High-Capacity (15K)
Black Toner Cartridge, Metered (15K)
106R01080
106R01156
Feed Roller Kit Contents - 604K35570
Name/Description Quantity
Feed Roller 1
Frame, Pickup 1
Plate, Pickup 1
Pick Roller 1
Feed Gear 1
Torque Limiter 1
Roller, Feed Now 1

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
