Xerox Phaser 7400 Service Manual

Error Messages and Codes 3-177
Warning Messages
No Paper in Tray 1 (MPT)
The Tray 1 (MPT) No Paper Sensor indicates the tray is empty.
Initial Actions:
■ Cycle the printer's power.
■ If the problem persists follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ No Paper Sensor, PL4.2.89
■ No Paper Actuator, PL4.2.65
■ Print Engine Map 9 (page 10-12)
■ Print Engine Front Sensor Board (1/2) page 10-26
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1
Fill the tray.
Does the error occur even if the tray is full?
Go to Step 2. Complete
2
Check the following for evidence of fault or
damage:
■ No Paper Sensor
■ No Paper Actuator
Is there any damage?
Replace any
damaged parts.
Go to Step 3.
3
Test the Tray 1 (MPT) No Paper Sensor.
Run the Service Diagnostics No Paper
Sensor test.
Does the sensor function correctly?
Replace the Engine
Control Board
(
page 8-112).
Go to Step 4.
4
Check the No Paper Sensor signal.
Does the voltage level change across
MPTPAP-2 when the sensor is actuated?
Go to Step 5. Replace the No
Paper Sensor.
5
Check all pins on the FSNS Harness for
continuity.
Is the harness conductive?
Replace the Engine
Control Board
(
page 8-112).
Replace the FSNS
Harness.

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
