Xerox Phaser 7400 Service Manual

Error Messages and Codes 3-179
Left Side Output Tray is Closed
The Side Output Tray Detect Sensor indicates the tray is closed. This warning
typically occurs when side output (faceup) is requested and the tray is closed.
Initial Actions:
■ Cycle the printer's power.
■ If the problem persists follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Side Output Tray Detect Sensor, PL11.1.32
■ Side Output Tray, PL2.1.124
■ COVSNS Harness, PL11.1.34
■ Print Engine Map 2 (page 10-5)
■ Print Engine Map 11 (page 10-14)
■ Print Engine Rear Sensor Board (page 10-29)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1
Check the following for evidence of fault or
damage:
■ Tray Detect Sensor, PL11.1.32
■ Side Output Tray, PL2.1.124
Replace the parts
concerned.
Go to Step 2.
2
Test the Side Output Tray Detect Sensor.
NOTE: Door sensor tests are located under
the Interlock Switches sub-menu.
Run the Service Diagnostics Side Output
Tray test.
Does the sensor function correctly?
Replace the Engine
Control Board
(
page 8-112).
Go to Step 3.
3
Check the sensor connection.
Is P/J180 connected?
Go to Step 4. Reconnect the
sensor.
4
Replace the Side Output Tray Detect
Sensor.
Does the error persist?
Go to Step 5. Complete
5
Check all pins on the COVSNS Harness for
continuity.
Is the harness conductive?
Replace the Engine
Control Board
(
page 8-112).
Replace the
COVSNS Harness.

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
