Xerox Phaser 7400 Service Manual

1-16 Phaser 7400 Color Printer Service Manual
Functional Specifications
First Print Output Time
First Print Output Time (FPOT) is defined as a time from receipt of the print
command in Ready mode until the first page sourced from either Tray 1 or Tray 2 is
delivered to the Output Tray. Sourcing media from the optional trays increases FPOT.
Note
This does not include the execution times for the Boot Loader or POST which
vary depending on printer configuration.
*These conditions apply to the values in the table above:
Printer at Ready
A4 LEF paper
Plain paper mode
Functional Specifications
Characteristic Specification
Printing Process Imaging System: 4-tandem drums, electro-photographic system.
Exposure System: Light-emitting Diode (LED), 4 beams.
Development System: Dry type 2-component developer.
Fusing System: Heat fusing, free nip-belt system.
Color Medium Yellow, Magenta, Cyan, and Black Toner Cartridges
Resolution /
Addressability
Standard
Enhanced
600 x 600 dpi (default)
1200 x 600 dpi
600 x 600 (5-bit) dpi
Operating Modes Print Mode: Print Engine capable of making prints immediately.
Ready Mode: 10 seconds from completion of a print.
Sleep / Power Saver Mode: Entered after a specified period of Print Engine
inactivity since completion of the last print.
Maximum Color
Coverage
All configurations are 240%
Warm-up Time < 85 seconds from cold start (power off condition)
< 75 seconds from (Wake-up)
Print Mode
First Print Out Time* (maximum seconds)
Tray 1 (MPT) Tray 2 Tray 3 Tray 4 Tray 5 Tray 6
Monochrome 12.0 13.5 14 15 16
Color 13 15.5 16.5 17.5 18.5

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
