Xerox Phaser 7400 Service Manual

3-12 Phaser 7400 Color Printer Service Manual
Fatal Errors (Continued)
F116 Finisher Exit Failure 3-132
F133 Finisher Punch Side Registration Sensor Failure 3-133
F136 Finisher Punch Registration Sensor Failure 3-134
F138 Finisher Punch Backup RAM Failure 3-135
F132 Finisher Punch Communications Failure 3-136
F181 Finisher Punch Transfer Motor Failure 3-137
F134 Finisher Punch Motor Failure 3-138
F137 Finisher Backup RAM Failure 3-139
F139 Finisher Punch Dust Sensor Failure 3-140
Printer error - Contact service; report fault [nnn]
Where [nnn] is one of the codes described below.
F141 Finisher Punch Unit counter at end of life. The Punch count exceeds life limit. 3-141
F142 Finisher Staple Unit counter at end of life. The Staple count exceeds life limit. 3-142
F186 Finisher interface error. Communications lost with Finisher. 3-143
I97 Inverter Power Supply Error. 3-144
T3 Fuser belt thermistor short circuit. 3-145
T4 Fuser belt thermistor open circuit. 3-145
T5 Fuser belt thermistor temperature too high. 3-145
T6 Fuser belt thermistor temperature too low. 3-145
T7 Fuser release error. 3-145
T8 Fuser belt slack error. 3-145
U60 Job Offset Home Position error. Job Offset does not reach home position. 3-146
U61 Control Panel Communications Failure. 3-147
135 No data to the Yellow LED Head 3-148
136 No data to the Magenta LED Head 3-148
137 No data to the Cyan LED Head 3-148
138 No data to the Black LED Head. 3-148
172 Fuser compensation thermistor indicates temperature too high. 3-145
173 Fuser compensation thermistor indicates temperature too low. 3-145
176 Fuser compensation thermistor short error. 3-145
177 Fuser compensation thermistor open error. 3-145
Error Message Summary (Continued)
Error Control Panel Message Page

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
