Xerox Phaser 7400 Service Manual

Error Messages and Codes 3-11
Fatal Errors (Continued)
U26 Yellow Imaging Unit Failure 3-109
U27 Magenta Imaging Unit Failure 3-109
U28 Cyan Imaging Unit Failure 3-109
U29 Black Imaging Unit Failure 3-109
U30 Flash Hardware Failure 3-111
U31 Flash Software Failure 3-111
U32 Fuser Fan Failure 3-112
U33 Fuser 110v/220v Mismatch Failure 3-113
U34 Unsupported Duplex Unit ROM 3-114
U39 Unsupported Tray 2 ROM 3-115
U35 Unsupported Tray 3 ROM 3-116
U36 Unsupported Tray 4 ROM 3-116
U37 Unsupported Tray 5 ROM 3-116
U38 Unsupported Tray 6 ROM 3-116
U50 Unsupported Inverter Unit ROM 3-117
U55 Unsupported Finisher Unit ROM 3-118
H80 Hard Drive Failure 3-119
W16 Fuse Cut Error In Fuser 3-120
W17 Fuse Cut Error In Transfer Unit 3-121
W18 Fuse Cut Error In Cyan Imaging Unit 3-122
W19 Fuse Cut Error In Magenta Imaging Unit 3-122
W20 Fuse Cut Error In Yellow Imaging Unit 3-122
W21 Fuse Cut Error In Black Imaging Unit 3-122
F130 Controller to Engine Communications Failure 3-123
F131 Finisher Folder Sensor Failure 3-124
F103 Finisher Paddle Failure 3-125
F106 Finisher Stapler Swing Motor Failure 3-126
F111 Finisher Stapler Stack Handling Motor Failure 3-127
F110 Finisher Staple Motor Failure 3-128
F93 Finisher Jog Motor Failure 3-129
F115 Finisher Tray Lift Motor Failure 3-130
Error Message Summary (Continued)
Error Control Panel Message Page

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month
