Xerox Phaser 7400 Service Manual

Error Messages and Codes 3-171
Duplex Unit Clock Frequency Error
The clock frequency for the Duplex Unit Control Board CPU is inaccurate.
Applicable Status Code:
Code 931: The Duplex Unit’s CPU clock frequency is inaccurate.
Initial Actions:
■ Reseat the Duplex Unit.
■ Cycle the printer's power.
■ If the problem persists follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Motor Driver Board, PL2.1.10
■ Duplex Unit, PL16.1.1A
■ Print Engine Map 3 (page 10-6)
■ Print Engine Map 5 (page 10-8)
■ Print Engine Motor Driver Board (5/6) (page 10-35)
■ Print Engine Motor Driver Board (6/6) (page 10-36)
■ Options Map 4 Duplex Unit Controller Board
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1
Check the Duplex Unit connector for
damage.
Is the connector damaged?
Replace the
connector.
Go to Step 2.
2
Check all pins on the DUPLEX Harness for
continuity.
Disconnect the DUPLEX Harness.
Is the DUPLEX Harness conductive?
Replace the Duplex
Unit. If the error
persists, go to
Step
3.
Replace the
DUPLEX Harness.
3
Check all pins of the DRV1 harness for
continuity.
Disconnect the DRV1 ribbon cable.
Is the cable conductive?
Replace the Engine
Control Board
(
page 8-112).
Replace the DRV1
Harness.
