Xerox Phaser 7400 Service Manual

Reference A-13
Service Diagnostics Tests
Service Diagnostics Tests and Utilities
Menu Item Front Panel Display Results Functional Definition
Print Service Menu Map - Prints the service diagnostics menu map, exits diagnostics, runs
POST and returns printer to Ready.
General Status - Displays user-selected engine information.
Engine Status <No Status to Report>
<Error Message>
NOTE: Generally, staus does not
update while in test printing
mode. Do not assume that it
does.
No Status to Report = The printer
is online and ready to print.
Error Message = Displays an error
message that prevents printing.
Status is displayed sequentially,
one line at a time.
Jam Status <No Jams >
<Jam @>
<Jam2 @>
Status is scrollable using the Up
Arrow or Down Arrown buttons.
Jam @ indicates the first jam
location. Jam2 @ secondary jam
location(s). Clear all jams.
Engine Board
ROM Version
Engine Version is n.n.n
Duplex Version is n.n.n
Tray 3 Version is n.n.n
Tray 4 Version is n.n.n
Tray 5 Version is n.n.n
Tray 6 Version is n.n.n
Sub-CPU Version is n.n.n
Tray 2 Version is n.n.n
Finisher Version is n.n.n
Inverster Version is n.n.n
Loader Version is n.n.n
Displays the firmware version of
the engine and installed optionals.
Otherwise a _* is displayed to
indicate an incorrect version.
<press Back or Cancel to abort>
Printer
Configuration
Installed Memory is: nnnMB
Hard Drive is Present/Absent
Duplex is Present/Absent
Tray 1-n Installed
Displays installed memory.
Detects the Hard Drive.
Detects the Duplex Unit.
Detects the installed Trays.
<press Back or Cancel to abort>
Ambient Temp/
Humidity
Amb. Temp. is nnn deg.C (Celsius)
Amb. Hum. is nnn % (relative percent)
Displays the current Temperature
and Humidity for the printer.
<press Back or Cancel to abort>
Fuser
Temperature
Fuser Temp Upper is nnn deg.C
Fuser Temp Lower is nnn deg.C
Removed
Displays reported fuser
temperatures in degrees Celsius.
<press Back or Cancel to abort>

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
