Service Parts Disassembly 8-17
Left Side Cover
1. Open the Top Cover.
2. Remove the Duplex Unit, if present.
3. Remove 4 (metal, 10 mm) screws securing the Left Side Cover.
4. Using a screw driver, release the center tab on the bottom of the Left Side Cover.
5. Flex the Left Side Cover slightly and pull down on the cover to release it from the
printer.
s7400-180
Hook
Left Side Cover
To Next Page
