Xerox Phaser 7400 Service Manual

Error Messages and Codes 3-27
Jam at Door E
Paper misfeed jam between the Fuser and the Top Output Tray. Media reached the
Fuser Exit Sensor, but did not reach the Top Output Tray Stack Full Sensor on time.
This error represents a misfeed jam inside the Exit Assembly.
Applicable Status Code:
Code E1: Jam at Door E
Initial Actions:
■ Ensure that the Exit Assembly is free of obstructions.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Exit Assembly, PL11.1.0
■ Fuser Motor, PL2.1.9
■ Exit Gate Solenoid, PL11.1.17
■ Full Stack Sensor, PL11.1.39
■ Print Engine Map 5 (page 10-8)
■ Print Engine Map 11 (page 10-14)
■ Print Engine Rear Sensor Board (page 10-29)
■ Print Engine Motor Driver Board (2/6) (page 10-32)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1
Check the following for evidence of fault or
damage:
■ Door E
■ Fuser
■ Exit Rollers and drive gears
■ Stack Full Actuator
■ Exit Assembly
Is there any damage or debris?
Replace any
damaged parts.
Go to Step 2.
2
Test the Fuser Exit and Top Output Tray
Stack Full Sensors.
Do the sensors function correctly?
Go to Step 4. Replace the
sensor. If the error
persists, go to
Step
3.
3
Check all pins on the SNS Harness for
continuity.
Is the harness conductive?
Go to Step 4. Replace the SNS
Harness.

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
