3-124 Phaser 7400 Color Printer Service Manual
Finisher Fold Position Sensor Failure
An error was detected with the Fold Position Sensor.
Applicable Status Code:
Code F131: Fold Position Sensor failure
Initial Actions:
■ Cycle the printer's power.
■ If the problem persists follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Fold Position Sensor
■ Finisher Control Board
■ Options Map 1 Finisher Controller Board
■ Options Map 8 Finisher Sensor Locator
■ Options Finisher Controller to Sensors (2/3)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1
Test the Folding Position Sensor.
Run the Service Diagnostics Bookbinding
Position Sensor test.
Does the sensor function correctly?
Replace the
Finisher Control
Board.
Go to Step 2.
2
Check the sensor connection.
Is CN39 connected?
Go to Step 3. Reconnect the
sensor.
3
Replace the sensor.
Does the error persist?
Go to Step 4. Complete
4
Check all pins on the harness for continuity.
Is the harness conductive?
Replace the
Finisher Control
Board.
Replace the
harness.

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
