Xerox Phaser 7400

Service Parts Disassembly 8-37
6. Remove the Feed Roller Paper Guide to provide space to remove the rollers.
7. Remove the Feed and Retard Rollers by releasing the hook and sliding the roller
off the shaft.
Replacement Note
Match each replacement roller to the one being removed. All three rollers are
unique.
s7400-429
1
2
3
Feed Roller
Feed Roller Paper Guide
