8-140 Phaser 7400 Color Printer Service Manual
10. Release the 2 hooks that secure the Paper Size Switch to the holder.
Replacement Note
After replacement, check that the switch is aligned as shown.
Paper Size Switch
Holder
Hooks
s7400-519
s7400-408
Paper Size Switch Housing
Paper Size Switches
Bottom of Tray Recess (Inside Printer)
