Xerox Phaser 7400 Service Manual

Parts List 9-17
Parts List 4.1 Base Assembly - Service Parts List
No. Part Number Name/Description
0. 801K27780 Base Assembly
1. Plate Assy.-Bottom (with 2~7)
2. Plate-Bottom
3. Rubber-Foot
4. IMSA-9714N-14Z02 Connector-SQR (Optional Tray Connector)
5. CONN Cord-JST10P,AMP4P-AMP7PX2 (OPTION Harness)
6. Cup_Screw A (included in Screw Kit)
7. Cup-Screw-E L=6 (included in Screw Kit)
8. Pillar-F
9. Pillar-R
10. Plate-Stay-Caulking
11. Cover-switch
12. Shaft-Switch (Power Switch Linkage)
13. Switch-AC (Power Switch Actuator)
14. Link-Switch (Power Switch Link)
15. Spring-Switch
16. Plate-Rear
17. 130K74220 Sensor Assy.-(with 18~20) (Paper Size Switch Assy)
18. Holder-PS-Switch
19. HS12-0001 Switch-Push (Paper Size Switch)
20. CONN Cord-AMP5-AMP5P (PSIZE Harness)
21. Spring-PS
22. Clamp-Cable
23. Geard-Motor(1st) (Lift Motor)
24. Plate-Top-Welding
25. Plate-Rock
26. Lock-Cassette
27. Cup_Screw (S Tight M3) (included in Screw Kit)
28. Cup_Screw A (included in Screw Kit)

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
