Xerox Phaser 7400 Service Manual

Parts List 9-19
Parts List 4.2 Feeder Assembly - Service Parts List
ID No. Part Number Name/Description
0. 050K61890 Tray 2 Feeder Assembly
29. Plate-Motor-A
30. Plate-Motor-B
31. Gear-Hopping-Z68-19
32. Gear-Idle-Retard
33. Gear-Feed-Z53-18
34. Gear-Idle-Z48
35. 127E15660 Motor-Pulse (Feed Motor)
36. 127E15670 Motor-Pulse-Regist (Registration Motor)
37. Clamp-Cable
38. CONN Cord-AMP8P-JST4P,AMP4P (REGHOP Harness)
39. Cup_Screw (S Tight M3)
40. Plate-Retard-Caulking
41. Lever-Retard
42. Holder-Spring
43. Spring-Retard
44. Shaft-Retard
45. Bearing-Metal
46. Bearing-Metal
47. Gear-Z38(oneway) (included in Gear Kit)
48. Collar
49. Pin-Spring
50. Ring
51. Guide-Paper-Lower
52. Plate-Retard-F
53. Plate-Rail-R
54. Cup_Screw (S Tight M3)
55. Torque-Limiter-OTLV
56. Roller-Feed
57. Plate-Feed
58. Roller Assy.-Pick-Up (with 59~62)

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
