Xerox Phaser 7400 Service Manual

Parts List 9-21
91. CONN Cord-AMP9P-AMP3PX3 (TRYSNS2 Harness)
92. TappingScrew-B2 L=8
93. Ring
94. Spring-FG-CL1
95. Holder-PESNS
96. AMP3P-AMP3P CONN Cord-Wire (PAPEND Harness)
97. OR-S2C (Feeder Board)
98. CONN Cord-AMP10P-AMP10P (TRYSNS1 Harness)
99. Cover-SNS
100. Cup_Screw (S Tight M3) (included in Screw Kit)
101. BU03P-TR-PC-H(LF) Connector-Plug-
102. Plate-Grip
103. Plate-Grip-Sub
104. Cup_Screw (S Tight M3) (included in Screw Kit)
105. Cup_Screw A (included in Screw Kit)
106. Cup_Screw (S Tight M 3) (included in Screw Kit)
107. Roller-set-723
108. Roller-set-723
109. Roller-set-723
110. Roller-set-723
Parts List 4.2 Feeder Assembly - Service Parts List
ID No. Part Number Name/Description

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
