Xerox Phaser 7400 Service Manual

Parts List 9-27
Parts List 6.1 Front Assemblies - Service Parts List
No. Part Number Name/Description
0. 674K01380 Side-F-Assy
1. Plate-Side-F-Caulking
2. Plate-Rail-Front
3. Plate-Sracker-Front
4. Slider-LiftUP-F
5. Holder-Slider-F
6. Gear-Idle-Link
7. Bracket-Sensor- (Sensor Housing)
8. CONN Cord-AMP2P-SW (Waste Toner Reservoir Detect Switch)
9. OR-HAL (Waste Toner Reservoir Full Sensor)
10. CONN Cord-AMP3P-JST3P (CN4 Harness)
11. Spring-FG-SW-F
12. Label-Cover-OPT
13. Plate-Guide(L)
14. Plate-Base(OP)
15. Holder-Cover-Open-SW (Top Cover Interlock Switch Holder)
16. Cup_Screw (S Tight M3) (included in Screw Kit)
17. TappingScrew-B2 L=8 (included in Screw Kit)
18. CONN Cord-JST2P-SW (Top Cover Interlock Switch)
19. Ring
20. Cover-Guard(R) (Right Front Cover)
21. OR-HAL (Waste Toner Reservoir Auger Rotation Sensor
22. CONN Cord-JST6P-JST3PX2 (HALL1 harness)
23. 127E15160 Motor-Fan (Imaging Unit Fan)
24. Screw (SW+2W) (included in Screw Kit)
25. BU03P-TR-PC-H(LF) Connector-Plug-
26. Lever-CO-A
27. Lever-CO-B
28. Spring-Torsion-CO
29. Clamp-Cable
30. Clamp-Cable-Film
31. Plate-FG-Top-F-A
32. Plate-FG-Top-F-B

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
