Xerox Phaser 7400 Service Manual

Parts List 9-35
Parts List 9.1 Registration Sensor Assembly - Service Parts List
No Part Number Name/Description
62. 130K74230 Sensor-Regist- Assy
63. Cover-Connector (Registration Sensor Board Cover)
64. CONN Cord-AMP2P-AMP2P
65. 292254-2 Connector-Plug-
66. CONN Cord-AMP14P-AMP14P (CSNS Harness)
67. Sensor-Regist-Sub-Assy (with 68~85)
68. Plate-Po-Caulking
69. Spring-Shutter
70. Lever-Solenoid
71. Spring-Belt-Fix
72. DC-Solenoid (Registration Shutter Solenoid)
73. OR-S2Z (Registration Sensor Board)
74. GP2TC2 SENSOR-Dencity - (ADC Sensor)
75. Plate-Guard-Sensor (Registration Sensor Covers)
76. Shutter- Assy (Registration Shutter)
77. TARUMI-Sensor Assy (Media Slack Sensor Assy)
78. CONN Cord-AMP12P-MOLEX5P,AMP3P,AMP3P (DSNS Harness)
79. Plate-Beam
80. Cup_Screw (S Tight M3) (included in Screw Kit)
81. Screw (SW+2W) (included in Screw Kit)
82. Pin
83. Ring
84. Clamp-Cable

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
